“Extracts Eminence To Build Excellence”
We specialize in the field of Enameling. Our products are used in leading manufacturing firms in the field of motor pumps, transformers, compressors, alternators and home appliances for over 15 years. Our background comes from experienced leaders leading top brands in India such as EssellCables and Vmi. All products are manufactured as per Indian/ international Standards and specifications given by the customer.
... READ MORE
| Enamel Base | Polyester | Modified Polyester | Polyester Lmide | Dual Coat (Lmide-Amide) |
|---|---|---|---|---|
| Temperature Index | 130° | 155° | 180° | 200° |
| Thermal Class | B | F | H | H+ |
| Color | Light Brown to Brown | Brown | Brown | Light Brown |
| Range | 0.122mm to 4.0mm | 0.122mm to 4.0mm | 0.122mm to 4.0mm | 0.5mm to 2.0mm |
| I.S. Specification | I.S. – 13730 PT-34 | I.S. – 13730 PT-3 | I.S. – 13730 PT-8 | I.S. – 13730 PT-13 |
| Cut Through | 240°C | 270°C | 300°C | 320°C |
| Heat Stock | 155°C | 175°C | 200°C | 220°C |
| Abrasion Resistance Flexibility Solvent Resistance | Good | Good | Very Good | Excellent |
| Application | All General Electric Equipment | General Purpose Rotating and static electical equipment | For FHP Motors, Hand Tool, Electromagnetic Coils | Special Motors including hermetic motors, High speed winding machines |
| Special | Ideal for Rewinders | Balanced Electrical & Mechanical Properties Good for OEMs | Higher Thermal Endurance Excels in Thermaplastic Flow Abrasion & Heat Shock | Very High Thermal Property, Excellent for Hermetic use |
LAB TESTING EQUIPMENTS
- PORTABLE OHM METER
- ELONGATION TESTER (MOTORISED)
- SPRINGINESS TESTER (UPTO 1.600 MM)
- PEEL TESTER
- CUT THROUGH TESTER
- UNI DIRECTIONAL SCRAP ABRASION TESTER
- HIGH VOLTAGE BREAKDOWN TESTER (WITH SHORT BALL FACILITY)
- ELECTRICAL HEATED FORCED AIR CIRCULATED OVEN
- DC PIN HOLE TESTER (VOLTAGE CONTINUITY TEST)
- CO-EFFICIENT FRICTION TESTER
- ELECTRICAL RESISTANCE
- ELONGATION
- SPRINGINESS
- PEEL TEST
- CUT THROUGH
- HEAT SHOCK
- VOLTAGE BREAKDOWN
- RESISTANCE TO ABRASION
- ENAMEL TESTING
- CONTINUITY OF INSULATION
APPLICATIONS
TRANSFORMERS
MOTORS
APPLIANCES
AUTOMOTIVE
SWITCH GEARS
